Vostok 2409 Service Walkthrough Disassembly Pictures (Please sort by name in ascending order)
Vostok 2409 Service Walkthrough Assembly Pictures (Please sort by name in ascending order)
Being able to service the ETA calibre 2824-2 was a long-term goal and a dream when I started servicing and repairing watches some years ago. However, my first “calibre love” was the Vostok 2409; a reliable Soviet/Russian 17 jewels manual workhorse without any complications which has been around since 1970. It is still in production and found in Vostok’s Komandirskie series of watches, by some called the AK-47s of the watch world, together with its bigger brother the Vostok Amphibian dive watch.
Modern-day Vostok Amphibians use the automatic Vostok 2415 (w/o date complication) and 2416 (with date complication) calibres, but the Amphibian that I’m servicing in this walkthrough, an Albatross Radio Room, popular among collectors, is from the 1980s and in those days the manual 2409, as well as its predecessor 2209, was commonly used in the Amphibians as well as the Komandirskies.
While I was servicing this watch, I noticed that the crystal didn’t fit perfectly in the watch case. Being a serious dive watch originally designed for the Soviet navy this was, of course, unacceptable, so I replaced the crystal and video recorded the event in my “Bergeon No 5500 Crystal Press Review”.
For me, the 2409 was a great movement to get started with as it probably is the most affordable movement on the planet, and spare parts are readily available and cost next to nothing. A lost or damaged part never spells financial disaster. Also, eBay offers an abundance of used Vostok watches in decent condition housing this movement for as little as $20 and sometimes less. A brand new Vostok 2409 (www.meranom.com) can be had for as little as $27. Be aware that, almost without exception, the eBay listings always state that these Vostok watches have been serviced, but in my experience they never are. Well, maybe dipped in a can of naphtha, left to dry and then injected with a bit of oil here and there. I’ve seen horrible examples!
A somewhat tricky bit about the 2409 is to remove and replace the anti-shock springs. For this, I use a self-made tool made from peg wood. It’s shown in one of the assembly pictures together with a description of how I made it. A very similar tool is demonstrated in this video.
Later, as I was working myself through Mark Lovick’s watchrepairlessons.com courses, I trained with the Unitas 6498 pocket watch movement which is the selected movement for the courses. In all honesty, from a learning point, the Unitas 6498 would have been an easier movement to get started with (especially the anti-shock springs), but the tinkering with the Vostok 2409 was a low-cost and fun way to get started and made me better prepared for the courses which answered a bunch of questions and was amazingly instructive.
Eventually, I plan to publish a “Vostok 2414 Service Walkthrough”. The 2414 is identical to the 2409 but adds a very uncomplicated date complication.
So, if you want a whole lot of fun for next to nothing when it comes to money, there is no other movement I would recommend before the Vostok 24XX movements, and the 2409 is a great starting point if you have a desire to begin tinkering with watches. Be warned though; tinkering may take over a substantial chunk of your life!
Differences between Vostok 24XX parts: Introduction
I like the Vostok 24xx movements for several reasons, one of them being that they are so affordable. A mistake made never spells financial disaster. They have been reliable Russian/Soviet union workhorses for decades with (perhaps to some) surprisingly good accuracy. Another reason and the reason for this thread is that the parts of these movements most often are interchangeable, but not always!
Most of the time the parts used in these movements (2409, 2414, 2415, and 2416 being some of the most popular) are interchangeable, and the sellers on eBay often mix and match parts from non-working movements to build a working watch. For example, don’t be surprised if you find a train wheel bridge stamped 2409 (w/o date complication) mounted on a 2414 (w/ date complication) or vice versa.
As far as I know the Vostok 24xx movements have been in production since the early 1970-ties, and there are sometimes slight differences between the same parts between these movements and between generations of these movements. The purpose of this thread is to try to document these differences to facilitate any work made on these movements.
I’m a hobbyist, and what follows are my personal observations. I make mistakes and sometimes draw the wrong conclusions. When and if you spot my errors, please let me know!
I encourage anyone with any experience of the differences between the parts of these Vostok 24XX movements to contribute. Thank you!
My first topic will be about the click. Please see the next post!
I have a few old Vostok 24xx movements which seem perfectly fine except the the hairsprings are ruined. Most of these movements have come from eBay sold as “for parts or service”.
So, my plan is to buy a few new balance wheels complete with hairsprings (like these) and replace them. (I just haven't got the tools or skills to just replace the hairspring).
I have a pretty good idea about how to remove the hairspring stud (like this, or is there a better/easier way?), but how do I remove and re-fit the hairspring from the regulator arm? Can it just be lifted off and re-fitted with a tweezers, or do I need some special tool or procedure for this operation?
I haven’t seen any instructions or videos about this, perhaps because it’s so easy or obvious? Well, at least that’s what I’m hoping!
Sharing a few pics a Slava I got off the 'bay.
Sellers pic was a bit blur but it had a movement I liked and was advertised as running.
The crystal was pretty scratched up but it was running.
A Russian 2 piece case back.
Quickset date by pushing this ..well..pusher!
As you can see , the crystal has a very high 'rise' and this contributes to the overall thickness.
And this is the reason I bid for this watch..it has a Slava 2414 (or maybe a different number as it has day and date) with twin barrels. It looks pretty clean and the finishing is slightly better than the other Slava movements I've seen. Its running pretty well these last two days but I'll probably tear it down and take some pics and post them here.
I spent a few minutes with some sandpaper and autosol and managed to clean it up a bit. Interesting dial with some constellation around the edge of the dial and some Russian words where a minute track would usually be. Also some numbers. Anyone can shed someone light on this? Or speak Russian?
Hope everyone enjoyed their weekend. Mine is almost over as its 9pm here in Malaysia.
No registered users viewing this page.
I always habe been Interessen in mechanical watches since I was a young man. Now as I‘m retired I starten to „fix“ watches. I bought some Tools and a timegrapher. All watches now are optimized in accuracy. Except a Revue Thommen with a ETA 2824-2 movement. I stripped it partly, cleaned und libricated it and reassembled the Parts. Now ist is working even worse! Seams I have a lot to learn.... Glad to be here Reinhard
Had the head of screw strip off the mainspring barrel arbour. Tried to use a bergeon screw extractor and failed. So I set the arbour up in a lathe and graved a small cone center. Then I used circuit board drills and progressively drilled out the center. And after two broken bits, I finally got the insides loose. Then I went on my Stereo Microscope and picked out loose parts using rodico and a small pink screwdriver. All worked well. Now to find a new screw. The main mission was to replace a broken mainspring. And here is the broken mainspring. Sent from my iPhone using Tapatalk Pro
